Jimny SUMO GEAR Transfer Case Reduction Gears 15% High and Low (Automatic)
Availability: 3 in stock
Ships tomorrow if ordered in the next 1 day, 5 hours and 30 minutes!
Suzuki Jimny 2018-On Sumo 15% / 15% Transfer Box Reduction Gears - Automatic
Upgrade the gearing of your Suzuki Jimny 2018-on (JB64 / JB74) with these high-quality Sumo Gear transfer box reduction gears, manufactured in Japan for Generation 4 Jimny models fitted with a 4-speed automatic gearbox.
These reduction gears provide a 15% reduction in both high range and low range, helping compensate for larger diameter tyres while retaining more moderate gearing changes than extreme off-road reduction kits.
Manufactured from high-quality billet material and precision-machined in Japan by an original equipment gear manufacturer, Sumo gears are designed with an emphasis on strength, reliability and smooth, quiet operation.
IMPORTANT: Suitable for 4-speed automatic gearbox models with the original lever-operated transfer box only. Not suitable for manual gearbox vehicles.
15% High Range Reduction
The 15% high-range reduction helps compensate for the increased overall gearing caused by fitting larger diameter tyres.
This can improve low-speed drivability and help restore some of the mechanical advantage lost when upgrading from standard tyres to larger off-road tyres.
- Original high-range ratio: 1.32:1
- Sumo high-range ratio: 1.522:1
- Reduction: Approximately 15%
Please note: High-range gearing will also be reduced during normal road driving, resulting in higher engine RPM at a given road speed compared with standard gearing.
15% Low Range Reduction
The 15% low-range reduction provides lower gearing for off-road driving, helping improve vehicle control when tackling uneven terrain, steep inclines and technical obstacles.
Unlike more extreme reduction gear kits, these Sumo gears provide a moderate reduction in low range, making them particularly suitable for Jimnys running 29"-30" tyres.
- Original low-range ratio: 2.644:1
- Sumo low-range ratio: 3.05:1
- Reduction: Approximately 15%
Precision Manufactured in Japan
Sumo Gear reduction gears are manufactured in Japan by an original equipment gear manufacturer using precision machining equipment and high-quality billet material.
Each gear is designed with strength, reliability and accurate gear engagement in mind, helping provide smooth and quiet operation.
These gears are an excellent choice for Jimny owners looking for a quality Japanese-made gearing upgrade without the substantial low-range reduction offered by more extreme off-road gear sets.
Features
- Manufactured in Japan by Sumo Gear
- 15% high-range reduction
- 15% low-range reduction
- High-quality billet gear construction
- Precision-machined by an original equipment gear manufacturer
- Designed for strength, reliability and smooth operation
- Helps compensate for larger diameter tyres
- Recommended for 29"-30" tyres
- Designed for the Generation 4 Suzuki Jimny
- Suitable for 4-speed automatic gearbox models only
Specifications
- Manufacturer: Sumo Gear
- Country of manufacture: Japan
- High-range reduction: Approximately 15%
- Low-range reduction: Approximately 15%
- Original high-range ratio: 1.32:1
- Modified high-range ratio: 1.522:1
- Original low-range ratio: 2.644:1
- Modified low-range ratio: 3.05:1
- Recommended tyre size: 29"-30" (approximately 736-762mm)
- Transmission: 4-speed automatic gearbox only
- Transfer box: Lever-operated transfer box
- Vehicle generation: Suzuki Jimny Generation 4 (2018-on)
Vehicle Fitment
IMPORTANT: Suitable for 4-speed automatic gearbox models only.
- Suzuki Jimny JB64 - 2018-on (4-Speed Automatic)
- Suzuki Jimny JB74 - 2018-on (4-Speed Automatic)
- Suzuki Jimny Sierra - 2018-on (4-Speed Automatic)
Designed for Generation 4 Suzuki Jimny models fitted with the original 4-speed automatic gearbox and lever-operated transfer box.
NOT suitable for manual gearbox models.
Installation Information
Installation requires removal and dismantling of the transfer box to replace the original gearing.
Due to the mechanical work involved, professional installation or experience with transfer box rebuilding is recommended.
Installation Instructions:
Please note: These instructions are produced by Trail-Gear for their own reduction gears and show the older Generation 3 JB43 electric push-button transfer box. They are provided as a reference guide only, as the Generation 4 lever-operated transfer box shares many similar internal components. The Sumo gears are a different product, so some installation steps may differ.
Important Information
- 4-speed automatic gearbox models only - not suitable for manual vehicles.
- Reduces high-range gearing by approximately 15% and low-range gearing by approximately 15%.
- Both high-range and low-range gearing are changed by this conversion.
- Recommended for vehicles running 29"-30" tyres.
- Manufactured in Japan by Sumo Gear.
- The linked Trail-Gear installation instructions are provided for reference only and are not specific to this Sumo kit.
- Professional installation or experience rebuilding transfer boxes is recommended.
Please confirm your vehicle has a 4-speed automatic gearbox and the original lever-operated transfer box before ordering.
| Weight | 6.00 |
|---|
