Suzuki Grand Vitara 2005-2015 17x7 ET26 Black Modular Steel Wheel

Suzuki Grand Vitara 17" Black Modular Steel Wheel – 17x7J ET+26 Wide Offset

A heavy-duty 17" black modular steel wheel for the Suzuki Grand Vitara 2005–2015. With a 17x7J size and ET+26 offset, these wheels give the Grand Vitara a wider and more purposeful stance compared with the standard factory 17" wheels.

Designed specifically around the Grand Vitara's 5 x 114.3mm PCD and 60.1mm centre bore, these are an ideal choice for replacing damaged or corroded wheels or for upgrading to a tougher 4x4-style steel wheel.

Wheel Specifications

• Wheel diameter: 17"
• Wheel width: 7J
• Offset: ET+26
• PCD: 5 x 114.3mm
• Centre bore: 60.1mm
• Colour: Black
• Style: Modular steel wheel
• Construction: Steel
• Brand: Aftermarket

Fitment

• Suzuki Grand Vitara MK2 / JT – 2005 to 2015
• Designed for models using the 5 x 114.3mm PCD and 60.1mm centre bore

Please note: Specifications can vary depending on model, engine and market. Please check your existing wheel specification before ordering, particularly on imported or modified vehicles.

Wide Offset – Approximately 25mm Further Out

A common factory 17" Grand Vitara wheel specification is 17x6.5J ET45. These aftermarket wheels are 17x7J ET26, so they are both slightly wider and have a lower offset.

Compared with a standard 17x6.5J ET45 wheel, the outer edge of this wheel will sit approximately 25mm further out on each side. The inner edge also sits approximately 13mm further away from the suspension, providing additional inner clearance.

Across the vehicle, this gives approximately 50mm of additional overall wheel stance compared with the standard 17x6.5J ET45 setup.

In terms of the outer wheel position, this gives a similar effect to fitting approximately a 25mm wheel spacer behind the standard wheel, but achieves the wider stance through the wheel width and offset itself rather than using a separate spacer.

Modular 4x4 Style

The classic black modular steel wheel design works particularly well on the Grand Vitara, giving the vehicle a tougher and wider 4x4 appearance. They are a great choice for standard vehicles as well as Grand Vitaras fitted with all-terrain or off-road tyres.

Ideal For

• Replacing damaged or corroded original wheels
• Creating a wider and more purposeful stance
• Achieving a wider wheel position without using separate wheel spacers
• All-terrain and off-road tyre setups
• Road and off-road use
• Upgrading from the standard factory-style wheel

What's Included

Supplied as one 17x7J ET+26 black modular steel wheel.

Important Information

This is an aftermarket wheel and is not a Genuine Suzuki product. Tyres, wheel nuts and centre caps are not included unless otherwise stated.

The approximately 25mm change in outer wheel position is based on comparison with a 17x6.5J ET45 factory wheel. If your vehicle currently has a different size or offset wheel, the change in position will differ.

Please check wheel and tyre clearance before fitting, particularly when using oversized tyres or on vehicles with modified suspension.
