Genuine Suzuki Jimny Front Differential Bolt - G13 - No 23

Genuine Suzuki Jimny Front Differential Bolt - G13 - No.23 (09117-08102)

Position number: 23

Description

This is a genuine Suzuki front differential bolt for Suzuki Jimny models fitted with the G13 engine. It is used within the front differential assembly to securely fasten the differential components, providing the correct factory fit and strength required for reliable drivetrain operation.

Key Features

Genuine Suzuki OEM bolt for exact fit and specification.
Designed for the front differential assembly.
Bolt size: 8 x 32 mm.
High-strength construction suitable for drivetrain applications.
Direct replacement for the original Suzuki fixing.

Fitment

Suzuki Jimny – G13 engine models.
OEM part number: 09117-08102.
Position number: 23 in the Suzuki parts diagram.
Front differential application.

When to replace

If the original bolt is damaged or corroded.
If the threads are worn or stripped.
If the bolt has been lost during differential repairs.
When rebuilding or servicing the front differential assembly.

What’s included

One genuine Suzuki front differential bolt (No.23) – part number 09117-08102.

Notes

Sold as one individual bolt. The Suzuki parts catalogue identifies 09117-08102 as an 8 x 32 mm differential bolt. Always tighten differential fasteners to the correct Suzuki torque specification during installation.
